61-8640.11
ActiveEAO
CONTACT BLOCK, 5 A, 250 V, SLOW-MAKE, 1 POLE, SCREW, SPST-NC
Deep-Dive with AI
Search across all available documentation for this part.
61-8640.11
ActiveEAO
CONTACT BLOCK, 5 A, 250 V, SLOW-MAKE, 1 POLE, SCREW, SPST-NC
Deep-Dive with AI
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | 61-8640.11 | 61-8640 Series |
|---|---|---|
| (Select First, Then Apply Filters) Compatible Series | EAO, 61 | EAO, 61 |
| Circuit | SPST-NC | SPST-NC |
| Contact Rating @ Voltage | 250 VAC, 5 A | 0.3 - 250 VAC |
| Requires | Switch Body | Switch Body |
| Termination Style | Screw Terminal | Screw Terminal, Quick Connect, Solder |
| Termination Style | - | 0.11 in |
| Termination Style | - | 2.8 mm |
61-8640 Series
CONTACT BLOCK, 5 A, 250 V, SLOW-MAKE, 1 POLE, SCREW, SPST-NC
| Part | (Select First, Then Apply Filters) Compatible Series | Termination Style | Contact Rating @ Voltage | Circuit | Requires | Termination Style | Termination Style |
|---|---|---|---|---|---|---|---|
EAO 61-8640.11 | 61, EAO | Screw Terminal | 5 A, 250 VAC | SPST-NC | Switch Body | ||
EAO 61-8640.17 | 61, EAO | Quick Connect, Solder | 5 A, 250 VAC | SPST-NC | Switch Body | 0.11 in | 2.8 mm |
EAO 61-8640.37 | 61, EAO | Quick Connect, Solder | 0.3 A, 50 VAC/DC | SPST-NC | Switch Body | 0.11 in | 2.8 mm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
61-8640 Series
Configurable Contact Block SPST-NC 5A @ 250VAC/DC
