LCAS8-56-L
Terminal Connector Rectangular Rectangular Tongue 8 AWG 5/16 Stud
Technical Specifications
Parameters and characteristics for this part
| Specification | LCAS8-56-L |
|---|---|
| Color | Red |
| Contact Finish | Electro-Tin |
| Contact Material | Copper |
| Diameter - Barrel ID | 0.18 in |
| Diameter - Barrel OD | 0.27 in |
| Diameter - Ring ID | 0.34 in |
| Insulation | Non-Insulated |
| Length - Overall | 1.32 in |
| Mounting Type | Free Hanging (In-Line) |
| Stud/Tab Size | 0.3125 in |
| Stud/Tab Size | 16 Stud, 5 Stud |
| Stud/Tab Size (Type) | Stud |
| Tab Thickness | 0.05 in |
| Terminal Style | Single Stud Hole |
| Terminal Type | Rectangular Tongue |
| Termination | Barrel, Crimb |
| Width - Outer Edges | 0.56 in |
| Wire Gauge | 8 AWG |
