C4532C0G1H473J160KA
NRNDTDK Corporation
CAP CER 0.047UF 50V C0G 1812
C4532C0G1H473J160KA
NRNDTDK Corporation
CAP CER 0.047UF 50V C0G 1812
Description
General part information
C4532C0G1H473J160KA
0.047 µF ±5% 50V Ceramic Capacitor C0G, NP0 1812 (4532 Metric)
Technical Specifications
Parameters and characteristics for this part
| Specification | C4532C0G1H473J160KA |
|---|---|
| Applications | General Purpose |
| Capacitance | 47 nF |
| Features | Low ESL |
| Mounting Type | Surface Mount, MLCC |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | 1812 (4532 Metric) |
| Size / Dimension Length | 0.177 in |
| Size / Dimension Width | 0.126 in |
| Temperature Coefficient | NP0, C0G |
| Thickness (Max) | 0.071 in |
| Tolerance | 5 % |
| Voltage - Rated | 50 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
