Specification	2011962322

Color	Red
Connector Type	Receptacle
Contact Termination	Crimp
Contact Type	Female Socket
Fastening Type	Latch Lock
Insulation Material	Polyester, Polybutylene Terephthalate (PBT)
Mounting Type	Free Hanging (In-Line)
Note	Contacts Not Included
Number of Positions	32
Number of Rows	2
Operating Temperature (Max)	105 °C
Operating Temperature (Min)	-40 °C
Pitch	0.079 in

201196 Series

...

Part	Number of Positions	For Use With/Related Products	Accessory Type	Note	Fastening Type	Contact Type	Contact Termination	Insulation Material	Number of Rows	Operating Temperature (Min)	Operating Temperature (Max)	Mounting Type	Pitch	Connector Type	Color
Molex 2011964040	4	201196 201200 Series	Terminal Position Assurance (TPA)
Molex 2011962203	20			Contacts Not Included	Latch Lock	Female Socket	Crimp	Polybutylene Terephthalate (PBT) Polyester	2	-40 °C	105 °C	Free Hanging (In-Line)	0.079 in	Receptacle	Yellow
Molex 2011962102	10			Contacts Not Included	Latch Lock	Female Socket	Crimp	Polybutylene Terephthalate (PBT) Polyester	2	-40 °C	105 °C	Free Hanging (In-Line)	0.079 in	Receptacle	Red
Molex 2011962204	20			Contacts Not Included	Latch Lock	Female Socket	Crimp	Polybutylene Terephthalate (PBT) Polyester	2	-40 °C	105 °C	Free Hanging (In-Line)	0.079 in	Receptacle	Blue
Molex 2011962141	14			Contacts Not Included	Latch Lock	Female Socket	Crimp	Polybutylene Terephthalate (PBT) Polyester	2	-40 °C	105 °C	Free Hanging (In-Line)	0.079 in	Receptacle	Black
Molex 2011964070	7	201196 201200 Series	Terminal Position Assurance (TPA)
Molex 2011964110	11	201196 201200 Series	Terminal Position Assurance (TPA)
Molex 2011962364	36			Contacts Not Included	Latch Lock	Female Socket	Crimp	Polybutylene Terephthalate (PBT) Polyester	2	-40 °C	105 °C	Free Hanging (In-Line)	0.079 in	Receptacle	Blue
Molex 2011962342	34			Contacts Not Included	Latch Lock	Female Socket	Crimp	Polybutylene Terephthalate (PBT) Polyester	2	-40 °C	105 °C	Free Hanging (In-Line)	0.079 in	Receptacle	Red
Molex 2011964150	15	201196 201200 Series	Terminal Position Assurance (TPA)
