Description
General part information
CSHB0415-6R8M
6.8 µH Shielded Molded Inductor 3.2 A 168mOhm Max Nonstandard
Technical Specifications
Parameters and characteristics for this part
| Specification | CSHB0415-6R8M |
|---|---|
| Current - Saturation (Isat) | 3.2 A |
| Current Rating | 3.2 A |
| DC Resistance (DCR) (Max) | 168 mOhm |
| Height - Seated (Max) | 0.059 in |
| Inductance | 6.8 µH |
| Inductance Frequency - Test | 100 kHz |
| Material - Core | Alloy Powder |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | 2-SMD, Nonstandard |
| Shielding | Shielded |
| Size / Dimension Length | 0.173 in |
| Size / Dimension Width | 0.165 in |
| Tolerance | 20 % |
| Type | Molded |
