5434094
ActivePhoenix Contact
PLUGGABLE TERMINAL BLOCKS BCH-508V-22
5434094
ActivePhoenix Contact
PLUGGABLE TERMINAL BLOCKS BCH-508V-22
Description
General part information
5434094
22 Position Terminal Block Header, Male Pins, Shrouded (2 Side) 0.200" (5.08mm) Vertical Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | 5434094 |
|---|---|
| Color | Gray |
| Contact Mating Finish | Tin |
| Contact Tail Length | 0.154 in |
| Current - IEC | 12 A |
| Current - UL | 15 A |
| Header Orientation | Vertical |
| Housing Material | Nylon, Polyamide, PA |
| Insulation Height | 0.472 in |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Through Hole |
| Number of Levels | 1 |
| Number of Positions | 22 |
| Pitch | 5.08 mm |
| Positions Per Level | 22 |
| Termination Style | Solder |
| Type | Male Pins, Shrouded (2 Side), Header |
| Voltage - IEC | 400 V |
| Voltage - UL | 300 V |
