IHSM4825ER821L
ActiveVishay Dale
FIXED IND 820UH 260MA 6.04OHM SM
IHSM4825ER821L
ActiveVishay Dale
FIXED IND 820UH 260MA 6.04OHM SM
Description
General part information
IHSM4825ER821L
820 µH Unshielded Inductor 260 mA 6.04Ohm Max Nonstandard
Technical Specifications
Parameters and characteristics for this part
| Specification | IHSM4825ER821L |
|---|---|
| Current - Saturation (Isat) | 0.17 mA |
| Current Rating | 0.26 A |
| DC Resistance (DCR) (Max) | 6.04 Ohm |
| Height - Seated (Max) | 0.225 in |
| Inductance | 0.82 mH |
| Inductance Frequency - Test | 1 kHz |
| Material - Core | Ferrite |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Nonstandard |
| Shielding | Unshielded |
| Size / Dimension Length | 0.54 in |
| Size / Dimension Width | 0.25 in |
| Tolerance | 15 % |
