Description
General part information
AM1SR-1203SJZ
Isolated Module DC DC Converter 1 Output 3.3V 200mA 11.4V - 12.6V Input
Technical Specifications
Parameters and characteristics for this part
| Specification | AM1SR-1203SJZ |
|---|---|
| Applications | ITE (Commercial) |
| Current - Output (Max) | 200 mA |
| Efficiency | 68 % |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | 4-SIP Module |
| Power (Watts) | 660 mW |
| Size / Dimension Height | 0.4 in |
| Size / Dimension Length | 0.46 in |
| Size / Dimension Width | 0.24 in |
| Standard Number | 62368-1 |
| Type | Isolated Module |
| Voltage - Input (Max) | 12.6 V |
| Voltage - Input (Min) | 11.4 V |
| Voltage - Isolation | 1500 Vrns |
| Voltage - Output 1 | 3.3 V |
