Specification	AMI-27-12-1

Applications	General Purpose
Approval Agency	cURus, CE
Configuration	Two Stage
Current	12 A
Filter Type	Single Phase
Frequency - Operating (Max)	400 Hz
Frequency - Operating (Min)	0 Hz
Inductance	6.5 mH
Mounting Type	Chassis Mount
Operating Temperature (Max)	100 °C
Operating Temperature (Min)	-25 °C
Termination Style	Quick Connect
Voltage - Rated AC	250 V

AMI-27 Series

Part	Inductance	Frequency - Operating (Max)	Approval Agency	Termination Style	Voltage - Rated AC	Mounting Type	Current	Operating Temperature (Min)	Operating Temperature (Max)	Filter Type	Configuration	Applications
Altran Magnetics, LLC AMI-27A-16-3	5.6 mH	400 Hz	CE cURus	Quick Connect Threaded Post (M4) Wire Leads	250 V	Chassis Mount	16 A	-25 °C	100 °C	Single Phase	Two Stage	Safety
Altran Magnetics, LLC AMI-27A-3-1		400 Hz	CE cURus	Quick Connect	250 V	Chassis Mount	3 A	-25 °C	100 °C	Single Phase	Two Stage	Safety
Altran Magnetics, LLC AMI-27-16-1	5.6 mH	400 Hz	CE cURus		250 V	Chassis Mount	16 A	-25 °C	100 °C	Single Phase	Two Stage	General Purpose
Altran Magnetics, LLC AMI-27-6-1		400 Hz	CE cURus	Quick Connect	250 V	Chassis Mount	6 A	-25 °C	100 °C	Single Phase	Two Stage	General Purpose
Altran Magnetics, LLC AMI-27A-6-1		400 Hz	CE cURus	Quick Connect	250 V	Chassis Mount	6 A	-25 °C	100 °C	Single Phase	Two Stage	Safety
Altran Magnetics, LLC AMI-27B-6-3	15.6 mH	400 Hz	CE cURus	Quick Connect	250 V	Chassis Mount	6 A	-25 °C	100 °C	Single Phase	Two Stage	Medical
Altran Magnetics, LLC AMI-27-12-3	6.5 mH	400 Hz	CE cURus	Quick Connect	250 V	Chassis Mount	12 A	-25 °C	100 °C	Single Phase	Two Stage	General Purpose
Altran Magnetics, LLC AMI-27-16-3	5.6 mH	400 Hz	CE cURus		250 V	Chassis Mount	16 A	-25 °C	100 °C	Single Phase	Two Stage	General Purpose
Altran Magnetics, LLC AMI-27-1-3	44 mH	400 Hz	CE cURus	Quick Connect	250 V	Chassis Mount	1 A	-25 °C	100 °C	Single Phase	Two Stage	General Purpose
Altran Magnetics, LLC AMI-27A-16-1	5.6 mH	400 Hz	CE cURus	Quick Connect Threaded Post (M4) Wire Leads	250 V	Chassis Mount	16 A	-25 °C	100 °C	Single Phase	Two Stage	Safety
