85230 3681000

Active

Belden Inc.

CABLE 2CON 20AWG CLR SHLD

Search across all available documentation for this part.

Active

Belden Inc.

CABLE 2CON 20AWG CLR SHLD

Technical Specifications

Parameters and characteristics for this part

Specification	85230 3681000

Cable Type	Multi-Conductor
Conductor Insulation	Ethylene Tetrafluoroethylene (ETFE)
Conductor Material	Copper, Tinned
Conductor Strand [custom]	28
Conductor Strand [custom]	7
Features	Drain Wire
Jacket (Insulation) Diameter [diameter]	0.182 in
Jacket (Insulation) Diameter [diameter]	4.62 mm
Jacket (Insulation) Material	Ethylene Tetrafluoroethylene (ETFE)
Jacket (Insulation) Thickness	0.02 in
Jacket (Insulation) Thickness	0.508 mm
Jacket Color	Clear
Length	1000 ft
Length	304.8 m
Number of Conductors	2
Operating Temperature [Max]	150 °C
Operating Temperature [Min]	-60 °C
Shield Coverage	100 %
Shield Material	Aluminum
Shield Type	Foil
Usage	Audio, Instrumentation, Control
Wire Gauge	20 AWG

Part	Length	Length	Cable Type	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Conductor Material	Shield Type	Number of Conductors	Conductor Insulation	Usage	Jacket Color	Operating Temperature [Max]	Operating Temperature [Min]	Jacket (Insulation) Material	Shield Material	Conductor Strand [custom]	Conductor Strand [custom]	Features	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Wire Gauge	Shield Coverage
Belden Inc. 85230 3681000	1000 ft	304.8 m	Multi-Conductor	0.02 in	0.508 mm	Copper Tinned	Foil	2	Ethylene Tetrafluoroethylene (ETFE)	Audio Control Instrumentation	Clear	150 °C	-60 °C	Ethylene Tetrafluoroethylene (ETFE)	Aluminum	28	7	Drain Wire	0.182 in	4.62 mm	20 AWG	100 %

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	1000	$ 11.90

General part information

2 Conductor Multi-Conductor Cable Clear 20 AWG Foil 1000.0' (304.8m)
