DS2117MX/T&R
ActiveAnalog Devices Inc./Maxim Integrated
IC TERM SCSI LVD/SE ULT-3 FCHIP
Deep-Dive with AI
Search across all available documentation for this part.
DS2117MX/T&R
ActiveAnalog Devices Inc./Maxim Integrated
IC TERM SCSI LVD/SE ULT-3 FCHIP
Deep-Dive with AI
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | DS2117MX/T&R | DS2117M Series |
|---|---|---|
| Mounting Type | Surface Mount | Surface Mount |
| Number of Terminations | 9 | 9 |
| Operating Temperature [Max] | 70 °C | 70 °C |
| Operating Temperature [Min] | 0 °C | 0 °C |
| Package / Case | 36-BSOP | 36-BSOP |
| Package / Case [y] | 0.295 in | 0.295 in |
| Package / Case [y] | 7.5 mm | 7.5 mm |
| Supplier Device Package | 36-SSOP | 36-SSOP |
| Type | SE, LVD, SCSI | SE, LVD, SCSI |
| Voltage - Supply [Max] | 5.5 V | 5.5 V |
| Voltage - Supply [Min] | 4 V | 4 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
DS2117M Series
IC TERM SCSI LVD/SE ULT-3 FCHIP
| Part | Package / Case | Package / Case [y] | Package / Case [y] | Supplier Device Package | Type | Number of Terminations | Operating Temperature [Max] | Operating Temperature [Min] | Mounting Type | Voltage - Supply [Max] | Voltage - Supply [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc./Maxim Integrated DS2117MX/T&R | 36-BSOP | 0.295 in | 7.5 mm | 36-SSOP | LVD, SCSI, SE | 9 | 70 °C | 0 °C | Surface Mount | 5.5 V | 4 V |
Analog Devices Inc./Maxim Integrated DS2117MB | 36-BSOP | 0.295 in | 7.5 mm | 36-SSOP | LVD, SCSI, SE | 9 | 70 °C | 0 °C | Surface Mount | 5.5 V | 4 V |
Description
General part information
DS2117M Series
SCSI, LVD, SE Terminator 9 Terminations 36-SSOP
