General part information
Pluggable Terminal Blocks 6 Pos 5mm pitch Through Hole Header
Technical documentation and resources
Parameters and characteristics commom to parts in this series
| Specification | 1734313 | CCDN Series |
|---|---|---|
| Color | Black | Black |
| Contact Mating Finish | Tin | Tin |
| Contact Tail Length | 0.102 in | 0.102 in |
| Contact Tail Length | 2.6 mm | 2.6 mm |
| Current - IEC | 12 A | 12 A |
| Current - UL | 10 A | 10 A |
| Features | - | Mating Flange |
| Header Orientation | 90°, Right Angle | 90°, Right Angle |
| Housing Material | Liquid Crystal Polymer (LCP) | Liquid Crystal Polymer (LCP) |
| Insulation Height | 20.09 mm | 20.09 mm |
| Insulation Height | 0.791 in | 0.791 in |
| Material Flammability Rating | UL94 V-0 | UL94 V-0 |
| Mounting Type | Through Hole | Through Hole |
| Number of Levels | 2 | 2 |
| Number of Positions | 12 | 12 - 24 |
| Pitch [x] | 5 mm | 5 mm |
| Pitch [x] | 0.197 in | 0.197 in |
| Positions Per Level | 6 | 6 - 12 |
| Termination Style | Solder | Solder |
| Type | Header, Male Pins, Shrouded (4 Side) | Header, Male Pins, Shrouded (4 Side) |
| Voltage - IEC | 400 V | 400 V |
| Voltage - UL | 300 V | 300 V |
Pluggable Terminal Blocks 6 Pos 5mm pitch Through Hole Header
| Part | Voltage - UL | Voltage - IEC | Insulation Height | Insulation Height | Contact Tail Length | Contact Tail Length | Color | Material Flammability Rating | Current - UL | Header Orientation | Pitch [x] | Pitch [x] | Mounting Type | Number of Levels | Type | Contact Mating Finish | Number of Positions | Current - IEC | Termination Style | Positions Per Level | Housing Material | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Phoenix Contact 1734313 | 300 V | 400 V | 20.09 mm | 0.791 in | 0.102 in | 2.6 mm | Black | UL94 V-0 | 10 A | 90°, Right Angle | 5 mm | 0.197 in | Through Hole | 2 | Header, Male Pins, Shrouded (4 Side) | Tin | 12 | 12 A | Solder | 6 | Liquid Crystal Polymer (LCP) | |
Phoenix Contact 1734546 | 300 V | 400 V | 20.09 mm | 0.791 in | 0.102 in | 2.6 mm | Black | UL94 V-0 | 10 A | 90°, Right Angle | 5 mm | 0.197 in | Through Hole | 2 | Header, Male Pins, Shrouded (4 Side) | Tin | 24 | 12 A | Solder | 12 | Liquid Crystal Polymer (LCP) | Mating Flange |
