SG901-1066 ANTENNA

Active

Sagrad Inc.

RF ANT 2.4GHZ PCB TRACE IPEX SMD

Search across all available documentation for this part.

Active

Sagrad Inc.

RF ANT 2.4GHZ PCB TRACE IPEX SMD

Technical Specifications

Parameters and characteristics for this part

RF ANT 2.4GHZ PCB TRACE IPEX SMD

Part	Antenna Type	Frequency Range [Max]	Frequency Range [Min]	Termination	Gain	Mounting Type	Number of Bands	VSWR	Height (Max) [Max]	Height (Max) [Max]
Sagrad Inc. SG901-1066 ANTENNA	PCB Trace	2.49 GHz	2.4 GHz	IPEX MHF1, U.FL (UMCC)	3.8 dBi	Surface Mount	1	2	0.087 in	2.2 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

RF ANTENNA PCB Trace U.FL (UMCC), IPEX MHF1 Surface Mount
