AB-D2040-V24-Q
ActiveAmerican Bright Optoelectronics Corporation
100-240VAC INPUT, 24VDC OUTPUT,
AB-D2040-V24-Q
ActiveAmerican Bright Optoelectronics Corporation
100-240VAC INPUT, 24VDC OUTPUT,
Description
General part information
AB-D2040-V24-Q
1.67A 24V Constant Voltage LED Driver AC DC Converter Topology 1 Output
Technical Specifications
Parameters and characteristics for this part
| Specification | AB-D2040-V24-Q |
|---|---|
| Approval Agency | cULus, CE, cURus, TUV, UKCA |
| Current - Output (Max) | 1.67 A |
| Dimming | TRIAC, Non-Dimmable |
| Efficiency | 86 % |
| Features | OCP, SCP, OTP, OVP |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Operating Temperature (Max) | 45 °C |
| Operating Temperature (Min) | -20 °C |
| Power (Watts) | 40 W |
| Ratings | IP20 |
| Size / Dimension Height | 0.67 in |
| Size / Dimension Length | 6.14 in |
| Size / Dimension Width | 1.97 in |
| Termination Style | Screw Terminal |
| Topology | AC DC Converter |
| Type | Constant Voltage |
| Voltage - Input (Max) | 264 V |
| Voltage - Input (Min) | 90 VAC |
| Voltage - Output | 24 V |
