Specification	2132260310

Connector Type	Receptacle
Contact Finish - Mating	Gold
Contact Finish - Post	Tin
Contact Finish Thickness - Mating	3.94 µin
Contact Finish Thickness - Post	39.4 µin
Contact Material	Copper Alloy
Contact Type	Forked
Current Rating	0 A
Current Rating	Varies by Wire Gauge
Fastening Type	Latch Holder
Features	Solder Retention
Insulation Color	Natural
Insulation Height	0.252 in
Insulation Material	Nylon, Polyamide (PA)
Material Flammability Rating	UL94 V-0
Mounting Type	Right Angle, Surface Mount
Number of Positions	3
Number of Positions Loaded	All
Number of Rows	1
Operating Temperature (Max)	105 °C
Operating Temperature (Min)	-40 °C
Pitch - Mating	0.059 in
Style	Cable/Wire, Board
Termination	Solder
Voltage Rating	100 VAC
Voltage Rating (Type)	AC, DC

213226 Series

Headers & Wire Housings 1.50MM CLIK-MATE REC 02P RA AU

Part	Mounting Type	Number of Positions Loaded	Insulation Color	Voltage Rating	Voltage Rating (Type)	Features	Contact Finish - Mating	Operating Temperature (Min)	Operating Temperature (Max)	Current Rating	Number of Rows	Material Flammability Rating	Fastening Type	Contact Type	Connector Type	Contact Finish - Post	Pitch - Mating	Termination	Number of Positions	Contact Finish Thickness - Mating	Style	Insulation Height	Current Rating
Molex 2132261431
Molex 2132261430	Right Angle Surface Mount	All	Natural	100 VAC	AC DC	Solder Retention	Gold	-40 °C	105 °C	2 A	1	UL94 V-0	Detent Lock	Forked	Receptacle	Tin	0.059 in	Solder	14	15 µin	Board Cable/Wire	0.252 in
Molex 2132260531	Right Angle Surface Mount	All	Black	100 VAC	AC DC	Solder Retention	Gold	-40 °C	105 °C	0 A	1	UL94 V-0	Latch Holder	Forked	Receptacle	Tin	0.059 in	Solder	5	15 µin	Board Cable/Wire	0.252 in	Varies by Wire Gauge
Molex 2132260831
Molex 2132260971	Right Angle Surface Mount	All	Black	100 VAC	AC DC	Solder Retention	Gold	-40 °C	105 °C	0 A	1	UL94 V-0	Latch Holder	Forked	Receptacle	Tin	0.059 in	Solder	9	30 µin	Board Cable/Wire	0.252 in	Varies by Wire Gauge
Molex 2132261471
Molex 2132261331
Molex 2132260710	Right Angle Surface Mount	All	Natural	100 VAC	AC DC	Solder Retention	Gold	-40 °C	105 °C	2 A	1	UL94 V-0	Detent Lock	Forked	Receptacle	Tin	0.059 in	Solder	7	3.94 µin	Board Cable/Wire	0.252 in
Molex 2132261271
Molex 2132261030	Right Angle Surface Mount	All	Natural	100 VAC	AC DC	Solder Retention	Gold	-40 °C	105 °C	2 A	1	UL94 V-0	Detent Lock	Forked	Receptacle	Tin	0.059 in	Solder	10	15 µin	Board Cable/Wire	0.252 in
