BU-2031-A-36-0

Active

MUELLER ELECTRIC

ALLIGATOR CLIP TO BANANA PLUG , BLACK ROHS COMPLIANT: YES

Search across all available documentation for this part.

Active

MUELLER ELECTRIC

ALLIGATOR CLIP TO BANANA PLUG , BLACK ROHS COMPLIANT: YES

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	BU-2031-A-36-0	BU-2031 Series

1st Connector	Insulated, Miniature, Alligator Clip	Insulated, Miniature, Alligator Clip, Single, Stackable, Banana Plug
2nd Connector	Banana Plug, Single, Stackable	Banana Plug, Single, Stackable, Alligator Clip, Insulated
Cable Length	36 in	12 - 36 "
Cable Length	914.4 mm	304.8 - 914.4 mm
Configuration	Alligator to Banana Plug	Alligator to Banana Plug, Banana to Alligator
Contents	1 Lead, Black	1 Lead, Black, Red
Contents	-	1
Current Rating (Amps)	5 A	5 A
Material - Insulation	Poly-Vinyl Chloride (PVC)	Poly-Vinyl Chloride (PVC)
Stacking Method	-	Multi-Stacking, Front and Vertical
Temperature Range	105 °C	105 °C
Temperature Range	221 °F	221 °F
Type	-	Patch Cord
Voltage - Rated	300 V	300 V
Wire Gauge	20 AWG	20 AWG

MINIGATOR CLIP-4MM BANANA PLUG, BLK, 24" ROHS COMPLIANT: YES

Part	Voltage - Rated	Contents	Configuration	1st Connector	Cable Length	Cable Length	Wire Gauge	Current Rating (Amps)	2nd Connector	Temperature Range	Temperature Range	Material - Insulation	Contents [custom]	Type	Stacking Method
MUELLER ELECTRIC BU-2031-A-24-0	300 V	1 Lead, Black	Alligator to Banana Plug	Alligator Clip, Insulated, Miniature	24 "	609.6 mm	20 AWG	5 A	Banana Plug, Single, Stackable	105 °C	221 °F	Poly-Vinyl Chloride (PVC)
MUELLER ELECTRIC BU-2031-A-36-2	300 V	Red	Alligator to Banana Plug	Alligator Clip, Insulated, Miniature	36 in	914.4 mm	20 AWG	5 A	Banana Plug, Single, Stackable	105 °C	221 °F	Poly-Vinyl Chloride (PVC)	1
MUELLER ELECTRIC BU-2031-A-12-0		1 Lead, Black	Banana to Alligator	Banana Plug, Single, Stackable	12 in	304.8 mm	20 AWG		Alligator Clip, Insulated			Poly-Vinyl Chloride (PVC)		Patch Cord	Front and Vertical, Multi-Stacking
MUELLER ELECTRIC BU-2031-A-36-0	300 V	1 Lead, Black	Alligator to Banana Plug	Alligator Clip, Insulated, Miniature	36 in	914.4 mm	20 AWG	5 A	Banana Plug, Single, Stackable	105 °C	221 °F	Poly-Vinyl Chloride (PVC)
MUELLER ELECTRIC BU-2031-A-24-2	300 V	Red	Alligator to Banana Plug	Alligator Clip, Insulated, Miniature	24 "	609.6 mm	20 AWG	5 A	Banana Plug, Single, Stackable	105 °C	221 °F	Poly-Vinyl Chloride (PVC)	1
MUELLER ELECTRIC BU-2031-A-12-2		Red	Banana to Alligator	Banana Plug, Single, Stackable	12 in	304.8 mm	20 AWG		Alligator Clip, Insulated			Poly-Vinyl Chloride (PVC)	1	Patch Cord	Front and Vertical, Multi-Stacking

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

36.0" (914.40mm) Alligator Clip, Miniature, Insulated To Banana Plug, Single, Stackable Test Lead 300V 1 Lead, Black

Technical documentation and resources
