1091742
ActiveSICK, Inc.
PHOTOELEC SENSOR
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
1091742
ActiveSICK, Inc.
PHOTOELEC SENSOR
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 1091742 |
|---|---|
| Connection Method | Connector, M12 |
| Ingress Protection | IP67 |
| Light Source | 631 nm |
| Light Source | Red |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -40 °C |
| Output Configuration | PNP - Dark-ON |
| Response Time | 500 µs |
| Sensing Distance [Max] | 60 cm |
| Sensing Distance [Max] | 23.622 " |
| Sensing Distance [Min] | 5 mm |
| Sensing Distance [Min] | 0.197 in |
| Sensing Method | Proximity |
| Voltage - Supply [Max] | 30 VDC |
| Voltage - Supply [Min] | 10 VDC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 130.24 | |
| 10 | $ 111.81 | |||
Description
General part information
1091742
Proximity Optical Sensor 0.197" ~ 23.622" (5mm ~ 600mm) PNP - Dark-ON
