Specification	TFE161P32K7680R

ESR (Equivalent Series Resistance)	60 kOhm
Frequency	0.032768 MHz
Frequency Tolerance	10 ppm
Height - Seated (Max)	0.02 in
Height - Seated (Max) Length	0.063 in
Height - Seated (Max) Width	0.039 in
Load Capacitance	12.5 pF
Mounting Type	Surface Mount
Operating Mode	Fundamental
Operating Temperature (Max)	85 °C
Operating Temperature (Min)	-40 °C
Package / Case	No Lead, 2-SMD
Package Length	1.6 mm
Package Name	2-SMD
Package Width	1 mm
Size / Dimension Length	0.063 in
Size / Dimension Width	0.039 in
Type	kHz Crystal (Tuning Fork)

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Technical documentation and resources
