8445MN 004100

Obsolete

Belden Inc.

CABLE 5COND 22AWG YELLOW

Search across all available documentation for this part.

Obsolete

Belden Inc.

CABLE 5COND 22AWG YELLOW

Technical Specifications

Parameters and characteristics for this part

Specification	8445MN 004100

Cable Type	Multi-Conductor
Conductor Insulation	Polypropylene (PP)
Conductor Material	Copper, Tinned
Conductor Strand	34 AWG
Conductor Strand [custom]	19 Strands
Jacket (Insulation) Diameter [diameter]	0.167 "
Jacket (Insulation) Diameter [diameter]	4.24 mm
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC)
Jacket (Insulation) Thickness	0.406 mm
Jacket (Insulation) Thickness	0.016 in
Jacket Color	Yellow
Length [x]	30.5 m
Length [x]	100 ft
Number of Conductors	5
Operating Temperature [Max]	80 C
Operating Temperature [Min]	-20 C
Ratings	UL Style 2937
Usage	Audio, Instrumentation, Control
Voltage	300 V
Wire Gauge	22 AWG

Part	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Conductor Insulation	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Conductor Material	Jacket (Insulation) Material	Conductor Strand [custom]	Conductor Strand	Operating Temperature [Min]	Operating Temperature [Max]	Usage	Ratings	Number of Conductors	Length [x]	Length [x]	Jacket Color	Voltage	Cable Type	Wire Gauge
Belden Inc. 8445MN 004100	0.167 "	4.24 mm	Polypropylene (PP)	0.406 mm	0.016 in	Copper Tinned	Poly-Vinyl Chloride (PVC)	19 Strands	34 AWG	-20 C	80 C	Audio Control Instrumentation	UL Style 2937	5	30.5 m	100 ft	Yellow	300 V	Multi-Conductor	22 AWG

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

5 Conductor Multi-Conductor Cable Yellow 22 AWG 100.0' (30.5m)
