Description
General part information
NTC-E1024DF-M4
1A 24V Constant Current LED Driver AC DC Converter Topology 4 Output
Technical Specifications
Parameters and characteristics for this part
| Specification | NTC-E1024DF-M4 |
|---|---|
| Current - Output (Max) | 1 A |
| Features | SCP |
| Mounting Type | Chassis Mount |
| Number of Outputs | 4 |
| Operating Temperature (Max) | 40 °C |
| Operating Temperature (Min) | 0 °C |
| Power (Watts) | 96 W |
| Size / Dimension Height | 5 in |
| Size / Dimension Length | 4.06 in |
| Size / Dimension Width | 2.95 in |
| Termination Style | Terminal Block |
| Topology | AC DC Converter |
| Type | Constant Current |
| Voltage - Input (Max) | 30 V p-p |
| Voltage - Input (Min) | 24 V |
| Voltage - Output | 24 V |
