Description
General part information
2727-09J
47 µH Unshielded Toroidal Inductor 200 mA 4.7Ohm Max Radial, Vertical
Technical Specifications
Parameters and characteristics for this part
| Specification | 2727-09J |
|---|---|
| Current Rating | 0.2 A |
| DC Resistance (DCR) (Max) | 4.7 Ohm |
| Frequency - Self Resonant | 14 MHz |
| Height - Seated (Max) | 0.3 in |
| Inductance | 47 µH |
| Inductance Frequency - Test | 2.5 MHz |
| Material - Core | Iron |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Radial, Vertical |
| Q | 80 |
| Shielding | Unshielded |
| Size / Dimension Length | 0.28 in |
| Size / Dimension Width | 0.16 in |
| Tolerance | 5 % |
| Type | Toroidal |
