1783643
ActivePhoenix Contact
TERM BLOCK HDR 8POS 90DEG 5.08MM
1783643
ActivePhoenix Contact
TERM BLOCK HDR 8POS 90DEG 5.08MM
Description
General part information
1783643
8 Position Terminal Block Header, Male Pins, Shrouded (2 Side) 0.200" (5.08mm) 90°, Right Angle Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | 1783643 |
|---|---|
| Color | Gray |
| Contact Mating Finish | Tin |
| Contact Tail Length | 0.138 in |
| Current - IEC | 12 A |
| Header Orientation | Right Angle |
| Header Orientation Angle | 90 ° |
| Insulation Height | 0.339 in |
| Mounting Type | Through Hole |
| Number of Levels | 1 |
| Number of Positions | 8 |
| Pitch | 5.08 mm |
| Positions Per Level | 8 |
| Termination Style | Solder |
| Type | Male Pins, Shrouded (2 Side), Header |
| Voltage - IEC | 250 V |
