83394 002U500

Active

Belden Inc.

CABLE 2COND 22AWG RED SHLD

Search across all available documentation for this part.

Active

Belden Inc.

CABLE 2COND 22AWG RED SHLD

Technical Specifications

Parameters and characteristics for this part

Specification	83394 002U500

Cable Type	Multi-Conductor
Conductor Insulation	Fluorinated Ethylene-Propylene (FEP)
Conductor Material	Copper, Tinned
Conductor Strand [custom]	7
Conductor Strand [custom]	30 AWG
Features	Drain Wire
Jacket (Insulation) Diameter [diameter]	5.06 mm
Jacket (Insulation) Diameter [diameter]	0.199 in
Jacket (Insulation) Material	Silicone Rubber
Jacket (Insulation) Thickness	0.762 mm
Jacket (Insulation) Thickness	0.03 in
Jacket Color	Red
Length [x]	500 '
Length [x]	152.4 m
Number of Conductors	2
Operating Temperature [Max]	150 °C
Operating Temperature [Min]	-70 °C
Shield Coverage	100 %
Shield Material	Aluminum
Shield Type	Foil
Usage	Control, Communication, Instrumentation
Wire Gauge	22 AWG

Part	Shield Material	Wire Gauge	Usage	Conductor Material	Conductor Strand [custom]	Conductor Strand [custom]	Shield Coverage	Jacket Color	Features	Jacket (Insulation) Material	Number of Conductors	Cable Type	Shield Type	Length [x]	Length [x]	Operating Temperature [Max]	Operating Temperature [Min]	Conductor Insulation	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]
Belden Inc. 83394 002U500	Aluminum	22 AWG	Communication Control Instrumentation	Copper Tinned	7	30 AWG	100 %	Red	Drain Wire	Silicone Rubber	2	Multi-Conductor	Foil	500 '	152.4 m	150 °C	-70 °C	Fluorinated Ethylene-Propylene (FEP)	0.762 mm	0.03 in	5.06 mm	0.199 in

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

2 (1 Pair) Conductor Multi-Conductor Cable Red 22 AWG Foil 500.0' (152.4m)
