107146
ObsoleteBasler Inc.
2592 X 1944, 14 FPS, MONO
107146
ObsoleteBasler Inc.
2592 X 1944, 14 FPS, MONO
Description
General part information
107146
2592 X 1944, 14 FPS, MONO
Technical Specifications
Parameters and characteristics for this part
| Specification | 107146 |
|---|---|
| Color | Monochrome |
| Frames per Second | 14 fps |
| Height (Max) | 0.665 in |
| Interface | LVDS |
| Lens Mount | CS |
| Mounting Type | Chassis Mount |
| Package / Case | Module |
| Pixel Size (Length) | 2.2 um |
| Pixel Size (Width) | 2.2 um |
| Resolution Height | 1944 |
| Resolution Width | 2592 |
| Sensor | MT9P031 |
| Shutter | Rolling |
| Size / Dimension Length | 1.142 in |
| Size / Dimension Width | 1.142 in |
| Type | CMOS |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
No documents available
