BULT3P3

Active

STMicroelectronics

TRANS PNP 200V 3A SOT-32-3

Search across all available documentation for this part.

Active

STMicroelectronics

TRANS PNP 200V 3A SOT-32-3

Technical Specifications

Parameters and characteristics for this part

Specification	BULT3P3

Current - Collector (Ic) (Max) [Max]	3 A
Current - Collector Cutoff (Max) [Max]	100 µA
DC Current Gain (hFE) (Min) @ Ic, Vce [Min]	10
Mounting Type	Through Hole
Operating Temperature	150 °C
Package / Case	TO-225AA, TO-126-3
Power - Max [Max]	32 W
Supplier Device Package	SOT-32-3
Transistor Type	PNP
Vce Saturation (Max) @ Ib, Ic	500 mV
Voltage - Collector Emitter Breakdown (Max) [Max]	200 V

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

TRANS PNP 200V 3A SOT-32-3

Part	Current - Collector (Ic) (Max) [Max]	Package / Case	Mounting Type	Transistor Type	Current - Collector Cutoff (Max) [Max]	Operating Temperature	Power - Max [Max]	DC Current Gain (hFE) (Min) @ Ic, Vce [Min]	Voltage - Collector Emitter Breakdown (Max) [Max]	Supplier Device Package	Vce Saturation (Max) @ Ib, Ic
STMicroelectronics BULT3P3	3 A	TO-126-3, TO-225AA	Through Hole	PNP	100 µA	150 °C	32 W	10	200 V	SOT-32-3	500 mV

General part information

Bipolar (BJT) Transistor PNP 200 V 3 A 32 W Through Hole SOT-32-3

Technical documentation and resources
