1802951
ActivePhoenix Contact
TERM BLOCK HDR 12POS 5.08MM
1802951
ActivePhoenix Contact
TERM BLOCK HDR 12POS 5.08MM
Description
General part information
1802951
12 Position Terminal Block Header, Male Pins, Shrouded (4 Side) 0.200" (5.08mm) 90°, Right Angle Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | 1802951 |
|---|---|
| Color | Black |
| Contact Mating Finish | Tin |
| Contact Tail Length | 0.138 in |
| Current - IEC | 10 A |
| Header Orientation | Right Angle |
| Header Orientation Angle | 90 ° |
| Insulation Height | 1.122 in |
| Mounting Type | Through Hole |
| Number of Levels | 2 |
| Number of Positions | 12 |
| Pitch | 5.08 mm |
| Positions Per Level | 6 |
| Termination Style | Solder |
| Type | Shrouded (4 Side), Male Pins, Header |
| Voltage - IEC | 250 V |
