SRP0615-R47K
ObsoleteBourns Inc.
INDUCTOR POWER SHIELDED WIREWOUND 0.47UH 10% 100KHZ 20Q-FACTOR METAL ALLOY POWDER 12.5A 0.0088OHM DCR T/R
SRP0615-R47K
ObsoleteBourns Inc.
INDUCTOR POWER SHIELDED WIREWOUND 0.47UH 10% 100KHZ 20Q-FACTOR METAL ALLOY POWDER 12.5A 0.0088OHM DCR T/R
Description
General part information
SRP0615-R47K
470 nH Shielded Inductor 12.5 A 8.8mOhm Max Nonstandard
Technical Specifications
Parameters and characteristics for this part
| Specification | SRP0615-R47K |
|---|---|
| Current - Saturation (Isat) | 20 A |
| Current Rating | 12.5 A |
| DC Resistance (DCR) (Max) | 8.8 mOhm |
| Frequency - Self Resonant | 71 MHz |
| Height - Seated (Max) | 0.059 in |
| Inductance | 470 nH |
| Inductance Frequency - Test | 100 kHz |
| Material - Core | Metal |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Nonstandard |
| Q | 20 |
| Shielding | Shielded |
| Size / Dimension Length | 0.28 in |
| Size / Dimension Width | 0.264 in |
| Tolerance | 10 % |
