Description
General part information
14110313010334
3 Position Terminal Block Header, Male Pins, Shrouded (4 Side) 0.100" (2.54mm) 90°, Right Angle Surface Mount
Technical Specifications
Parameters and characteristics for this part
| Specification | 14110313010334 |
|---|---|
| Color | White |
| Contact Material | Copper Alloy |
| Contact Mating Finish | Tin |
| Current - UL | 6 A |
| Features | Board Guide |
| Header Orientation | Right Angle |
| Header Orientation Angle | 90 ° |
| Housing Material | Liquid Crystal Polymer, LCP |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Surface Mount |
| Number of Levels | 1 |
| Number of Positions | 3 |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Pitch | 0.1 in |
| Positions Per Level | 3 |
| Termination Style | Solder |
| Type | Shrouded (4 Side), Male Pins, Header |
| Voltage - UL | 160 V |
