CHL8550CRT

Obsolete

Infineon Technologies

IC GATE DRVR HALF-BRIDGE 10DFN

Search across all available documentation for this part.

Obsolete

Infineon Technologies

IC GATE DRVR HALF-BRIDGE 10DFN

Technical Specifications

Parameters and characteristics for this part

Specification	CHL8550CRT

Channel Type	Synchronous
Current - Peak Output (Source, Sink) [custom]	2 A
Current - Peak Output (Source, Sink) [custom]	2 A
Driven Configuration	Half-Bridge
Gate Type	N-Channel MOSFET
High Side Voltage - Max (Bootstrap) [Max]	35 V
Input Type	Non-Inverting
Logic Voltage - VIL, VIH	0.8 V, 1 V
Mounting Type	Surface Mount
Number of Drivers	2
Operating Temperature [Max]	125 ¯C
Operating Temperature [Min]	-40 °C
Package / Case	10-VFDFN Exposed Pad
Rise / Fall Time (Typ) [custom]	8 ns
Rise / Fall Time (Typ) [custom]	10 ns
Supplier Device Package	10-DFN (3x3)
Voltage - Supply [Max]	5.5 V
Voltage - Supply [Min]	4.5 V

Part	Number of Drivers	High Side Voltage - Max (Bootstrap) [Max]	Rise / Fall Time (Typ) [custom]	Rise / Fall Time (Typ) [custom]	Mounting Type	Input Type	Logic Voltage - VIL, VIH	Voltage - Supply [Min]	Voltage - Supply [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Supplier Device Package	Channel Type	Package / Case	Driven Configuration	Current - Peak Output (Source, Sink) [custom]	Current - Peak Output (Source, Sink) [custom]	Gate Type
Infineon Technologies CHL8550CRT	2	35 V	8 ns	10 ns	Surface Mount	Non-Inverting	0.8 V 1 V	4.5 V	5.5 V	-40 °C	125 ¯C	10-DFN (3x3)	Synchronous	10-VFDFN Exposed Pad	Half-Bridge	2 A	2 A	N-Channel MOSFET

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Half-Bridge Gate Driver IC Non-Inverting 10-DFN (3x3)
