Description

General part information

14120415002000

4 Position Terminal Block Header, Male Pins, Shrouded (4 Side) 0.150" (3.81mm) 90°, Right Angle Through Hole

Technical Specifications

Parameters and characteristics for this part

Specification14120415002000
ColorBlack
Contact MaterialCopper Alloy
Contact Mating FinishTin
Current - UL11 A
Header OrientationRight Angle
Header Orientation Angle90 °
Housing MaterialPPA, PA, Polyphthalamide, Polyamide, Nylon
Insulation Height0.276 in
Material Flammability RatingUL94 V-0
Mounting TypeThrough Hole
Number of Levels1
Number of Positions4
Operating Temperature (Max)110 °C
Operating Temperature (Min)-40 °C
Pitch0.15 in
Positions Per Level4
Termination StyleSolder
TypeShrouded (4 Side), Male Pins, Header
Voltage - UL300 V
