Part	Filament Material	Color	Operating Temperature (Min)	Operating Temperature (Max)	Filament Diameter	Features	Density (Min)	Density (Max)	Tensile Strength	Flex Strength	Density
Jabil Inc. JA3D-C1001032	PETG (Polyethylene Terephthalate Glycol-modified)	Natural	240 °C	250 °C	0.07 in
Jabil Inc. JA3D-C1001068	ABS (Acrylonitrile Butadiene Styrene)	Black	275 °C	295 °C	0.07 in	Reinforced	1.1 g/cm³	1.12 g/cm³	35.3 Mpa	59.8 Mpa
Jabil Inc. JA3D-C1001031	TPU (Thermoplastic Polyurethane)	Natural	220 °C	230 °C	0.112 in	Elastomeric Wear & Friction					1.2 g/cm³
Jabil Inc. JA3D-C1001317	PA (Polyamide)	Blue			0.112 in
Jabil Inc. JA3D-C1001029	PETG (Polyethylene Terephthalate Glycol-modified)	Natural	240 °C	250 °C	0.112 in						1.24 g/cm³
Jabil Inc. JA3D-C1001055	ABS (Acrylonitrile Butadiene Styrene)	Natural	275 °C	295 °C	0.112 in	Reinforced	1.1 g/cm³	1.12 g/cm³	35.3 Mpa	59.8 Mpa
Jabil Inc. JA3D-C1001073	PC (Polycarbonate)	Black	285 °C	305 °C	0.07 in	Flame-Retardant Wear & Friction			61 Mpa	93.9 Mpa	1.18 g/cm³
Jabil Inc. JA3D-C1001135	TPE (Thermoplastic Elastomer)	Black	240 °C	250 °C	0.112 in	Elastomeric Wear & Friction			6 Mpa		1.05 g/cm³
Jabil Inc. JA3D-C1001059	PC (Polycarbonate)	Natural	285 °C	305 °C	0.112 in	Flame-Retardant Wear & Friction			61 Mpa	93.9 Mpa	1.18 g/cm³
Jabil Inc. JA3D-C1001058	PC (Polycarbonate)	Natural	285 °C	305 °C	0.07 in	Flame-Retardant Wear & Friction			61 Mpa	93.9 Mpa	1.18 g/cm³
