T4112012021-000
ActiveTE Connectivity AMP Connectors
CONN PLUG FMALE 2POS GOLD SCREW
Deep-Dive with AI
Search across all available documentation for this part.
T4112012021-000
ActiveTE Connectivity AMP Connectors
CONN PLUG FMALE 2POS GOLD SCREW
Deep-Dive with AI
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | T4112012021-000 | T41120 Series |
|---|---|---|
| Applications | Industrial | Industrial |
| Backshell Material, Plating | Nickel, Brass | Glass Filled, Polybutylene Terephthalate (PBT), Nickel, Brass |
| Cable Opening | - | 4 - 6 mm |
| Cable Opening | - | 0.157 - 0.236 in |
| Cable Opening [Max] [custom] | 8 mm | 8 mm |
| Cable Opening [Max] [custom] | 0.315 in | 0.315 in |
| Cable Opening [Min] [custom] | 6 mm | 6 mm |
| Cable Opening [Min] [custom] | 0.236 in | 0.236 in |
| Color | Silver | Black, Silver |
| Connector Type | Female Sockets, Plug | Female Sockets, Plug |
| Contact Finish - Mating | Gold | Gold, Silver |
| Contact Finish Thickness - Mating | 3 µin | 3 - 80 µin |
| Contact Finish Thickness - Mating | 0.076 µm | 0.076 - 2.03 µm |
| Contact Material | Zinc Alloy | Zinc Alloy, Bronze |
| Current Rating (Amps) | 4 A | 2 - 4 A |
| Features | Coupling Nut, Backshell | Coupling Nut, Backshell |
| Ingress Protection | IP67 - Dust Tight, Waterproof | IP67 - Dust Tight, Waterproof |
| Insert Material | Nylon, Polyamide (PA) | Nylon, Polyamide (PA) |
| Mounting Type | Free Hanging (In-Line), Right Angle | Free Hanging (In-Line), Right Angle |
| Number of Positions | 2 | 2 - 8 |
| Operating Temperature [Max] | 85 °C | 85 °C |
| Operating Temperature [Min] | -40 °C | -40 °C |
| Orientation | A | A |
| Primary Material | Metal | Metal |
| Shell Finish | Nickel | Nickel |
| Shell Material | Brass | Brass |
| Shell Size - Insert | M12-2 | M12-4, M12-2, M12-3, M12-5, M12-8 |
| Shielding | Shielded | Unshielded, Shielded |
| Termination | Screw | Screw |
| Voltage Rating | 250 VDC | 30 - 250 VDC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 9.90 | |
| 10 | $ 8.95 | |||
| 100 | $ 7.77 | |||
| 1000 | $ 6.63 | |||
T41120 Series
CONN PLUG FMALE 4POS GOLD SCREW
| Part | Ingress Protection | Mounting Type | Shell Material | Connector Type | Backshell Material, Plating | Voltage Rating | Contact Material | Primary Material | Insert Material | Shell Finish | Cable Opening [Max] [custom] | Cable Opening [Min] [custom] | Cable Opening [Max] [custom] | Cable Opening [Min] [custom] | Operating Temperature [Max] | Operating Temperature [Min] | Termination | Color | Orientation | Features | Shielding | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Applications | Number of Positions | Contact Finish - Mating | Current Rating (Amps) | Shell Size - Insert | Cable Opening [diameter] | Cable Opening [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
TE Connectivity AMP Connectors T4112002041-000 | IP67 - Dust Tight, Waterproof | Free Hanging (In-Line), Right Angle | Brass | Female Sockets, Plug | Glass Filled, Polybutylene Terephthalate (PBT) | 250 VDC | Zinc Alloy | Metal | Nylon, Polyamide (PA) | Nickel | 8 mm | 6 mm | 0.315 in | 0.236 in | 85 °C | -40 °C | Screw | Black, Silver | A | Backshell, Coupling Nut | Unshielded | 3 µin | 0.076 µm | Industrial | 4 | Gold | 4 A | M12-4 | ||
TE Connectivity AMP Connectors T4112001022-000 | IP67 - Dust Tight, Waterproof | Free Hanging (In-Line), Right Angle | Brass | Female Sockets, Plug | Glass Filled, Polybutylene Terephthalate (PBT) | 250 VDC | Bronze | Metal | Nylon, Polyamide (PA) | Nickel | 85 °C | -40 °C | Screw | Black, Silver | A | Backshell, Coupling Nut | Unshielded | 80 µin | 2.03 µm | Industrial | 2 | Silver | 4 A | M12-2 | 4 mm, 6 mm | 0.157 in, 0.236 in | ||||
TE Connectivity AMP Connectors T4112011032-000 | IP67 - Dust Tight, Waterproof | Free Hanging (In-Line), Right Angle | Brass | Female Sockets, Plug | Brass, Nickel | 250 VDC | Bronze | Metal | Nylon, Polyamide (PA) | Nickel | 85 °C | -40 °C | Screw | Silver | A | Backshell, Coupling Nut | Shielded | 80 µin | 2.03 µm | Industrial | Silver | 4 A | M12-3 | 4 mm, 6 mm | 0.157 in, 0.236 in | |||||
TE Connectivity AMP Connectors T4112012041-000 | IP67 - Dust Tight, Waterproof | Free Hanging (In-Line), Right Angle | Brass | Female Sockets, Plug | Brass, Nickel | 250 VDC | Zinc Alloy | Metal | Nylon, Polyamide (PA) | Nickel | 8 mm | 6 mm | 0.315 in | 0.236 in | 85 °C | -40 °C | Screw | Silver | A | Backshell, Coupling Nut | Shielded | 3 Ąin | 0.076 Ąm | Industrial | 4 | Gold | 4 A | M12-4 | ||
TE Connectivity AMP Connectors T4112011042-000 | IP67 - Dust Tight, Waterproof | Free Hanging (In-Line), Right Angle | Brass | Female Sockets, Plug | Brass, Nickel | 250 VDC | Bronze | Metal | Nylon, Polyamide (PA) | Nickel | 85 °C | -40 °C | Screw | Silver | A | Backshell, Coupling Nut | Shielded | 80 µin | 2.03 µm | Industrial | 4 | Silver | 4 A | M12-4 | 4 mm, 6 mm | 0.157 in, 0.236 in | ||||
TE Connectivity AMP Connectors T4112011031-000 | IP67 - Dust Tight, Waterproof | Free Hanging (In-Line), Right Angle | Brass | Female Sockets, Plug | Brass, Nickel | 250 VDC | Zinc Alloy | Metal | Nylon, Polyamide (PA) | Nickel | 85 °C | -40 °C | Screw | Silver | A | Backshell, Coupling Nut | Shielded | 3 µin | 0.076 µm | Industrial | Gold | 4 A | M12-3 | 4 mm, 6 mm | 0.157 in, 0.236 in | |||||
TE Connectivity AMP Connectors T4112012032-000 | IP67 - Dust Tight, Waterproof | Free Hanging (In-Line), Right Angle | Brass | Female Sockets, Plug | Brass, Nickel | 250 VDC | Bronze | Metal | Nylon, Polyamide (PA) | Nickel | 8 mm | 6 mm | 0.315 in | 0.236 in | 85 °C | -40 °C | Screw | Silver | A | Backshell, Coupling Nut | Shielded | 80 µin | 2.03 µm | Industrial | Silver | 4 A | M12-3 | |||
TE Connectivity AMP Connectors T4112012042-000 | IP67 - Dust Tight, Waterproof | Free Hanging (In-Line), Right Angle | Brass | Female Sockets, Plug | Brass, Nickel | 250 VDC | Bronze | Metal | Nylon, Polyamide (PA) | Nickel | 8 mm | 6 mm | 0.315 in | 0.236 in | 85 °C | -40 °C | Screw | Silver | A | Backshell, Coupling Nut | Shielded | 80 µin | 2.03 µm | Industrial | 4 | Silver | 4 A | M12-4 | ||
TE Connectivity AMP Connectors T4112001052-000 | IP67 - Dust Tight, Waterproof | Free Hanging (In-Line), Right Angle | Brass | Female Sockets, Plug | Glass Filled, Polybutylene Terephthalate (PBT) | 60 VDC | Bronze | Metal | Nylon, Polyamide (PA) | Nickel | 85 °C | -40 °C | Screw | Black, Silver | A | Backshell, Coupling Nut | Unshielded | 80 µin | 2.03 µm | Industrial | Silver | 4 A | M12-5 | 4 mm, 6 mm | 0.157 in, 0.236 in | |||||
TE Connectivity AMP Connectors T4112001021-000 | IP67 - Dust Tight, Waterproof | Free Hanging (In-Line), Right Angle | Brass | Female Sockets, Plug | Glass Filled, Polybutylene Terephthalate (PBT) | 250 VDC | Zinc Alloy | Metal | Nylon, Polyamide (PA) | Nickel | 85 °C | -40 °C | Screw | Black, Silver | A | Backshell, Coupling Nut | Unshielded | 3 µin | 0.076 µm | Industrial | 2 | Gold | 4 A | M12-2 | 4 mm, 6 mm | 0.157 in, 0.236 in | ||||
TE Connectivity AMP Connectors T4112001051-000 | IP67 - Dust Tight, Waterproof | Free Hanging (In-Line), Right Angle | Brass | Female Sockets, Plug | Glass Filled, Polybutylene Terephthalate (PBT) | 60 VDC | Zinc Alloy | Metal | Nylon, Polyamide (PA) | Nickel | 85 °C | -40 °C | Screw | Black, Silver | A | Backshell, Coupling Nut | Unshielded | 3 µin | 0.076 µm | Industrial | Gold | 4 A | M12-5 | 4 mm, 6 mm | 0.157 in, 0.236 in | |||||
TE Connectivity AMP Connectors T4112012021-000 | IP67 - Dust Tight, Waterproof | Free Hanging (In-Line), Right Angle | Brass | Female Sockets, Plug | Brass, Nickel | 250 VDC | Zinc Alloy | Metal | Nylon, Polyamide (PA) | Nickel | 8 mm | 6 mm | 0.315 in | 0.236 in | 85 °C | -40 °C | Screw | Silver | A | Backshell, Coupling Nut | Shielded | 3 µin | 0.076 µm | Industrial | 2 | Gold | 4 A | M12-2 | ||
TE Connectivity AMP Connectors T4112001081-000 | IP67 - Dust Tight, Waterproof | Free Hanging (In-Line), Right Angle | Brass | Female Sockets, Plug | Glass Filled, Polybutylene Terephthalate (PBT) | 30 VDC | Zinc Alloy | Metal | Nylon, Polyamide (PA) | Nickel | 85 °C | -40 °C | Screw | Black, Silver | A | Backshell, Coupling Nut | Unshielded | 3 µin | 0.076 µm | Industrial | 8 | Gold | 2 A | M12-8 | 4 mm, 6 mm | 0.157 in, 0.236 in | ||||
TE Connectivity AMP Connectors T4112002081-000 | IP67 - Dust Tight, Waterproof | Free Hanging (In-Line), Right Angle | Brass | Female Sockets, Plug | Glass Filled, Polybutylene Terephthalate (PBT) | 30 VDC | Zinc Alloy | Metal | Nylon, Polyamide (PA) | Nickel | 8 mm | 6 mm | 0.315 in | 0.236 in | 85 °C | -40 °C | Screw | Black, Silver | A | Backshell, Coupling Nut | Unshielded | 3 µin | 0.076 µm | Industrial | 8 | Gold | 2 A | M12-8 | ||
TE Connectivity AMP Connectors T4112012082-000 | IP67 - Dust Tight, Waterproof | Free Hanging (In-Line), Right Angle | Brass | Female Sockets, Plug | Brass, Nickel | 30 VDC | Bronze | Metal | Nylon, Polyamide (PA) | Nickel | 8 mm | 6 mm | 0.315 in | 0.236 in | 85 °C | -40 °C | Screw | Silver | A | Backshell, Coupling Nut | Shielded | 80 µin | 2.03 µm | Industrial | 8 | Silver | 2 A | M12-8 | ||
TE Connectivity AMP Connectors T4112012051-000 | IP67 - Dust Tight, Waterproof | Free Hanging (In-Line), Right Angle | Brass | Female Sockets, Plug | Brass, Nickel | 60 VDC | Zinc Alloy | Metal | Nylon, Polyamide (PA) | Nickel | 8 mm | 6 mm | 0.315 in | 0.236 in | 85 °C | -40 °C | Screw | Silver | A | Backshell, Coupling Nut | Shielded | 3 µin | 0.076 µm | Industrial | Gold | 4 A | M12-5 | |||
TE Connectivity AMP Connectors T4112002042-000 | IP67 - Dust Tight, Waterproof | Free Hanging (In-Line), Right Angle | Brass | Female Sockets, Plug | Glass Filled, Polybutylene Terephthalate (PBT) | 250 VDC | Bronze | Metal | Nylon, Polyamide (PA) | Nickel | 8 mm | 6 mm | 0.315 in | 0.236 in | 85 °C | -40 °C | Screw | Black, Silver | A | Backshell, Coupling Nut | Unshielded | 80 µin | 2.03 µm | Industrial | 4 | Silver | 4 A | M12-4 | ||
TE Connectivity AMP Connectors T4112011021-000 | IP67 - Dust Tight, Waterproof | Free Hanging (In-Line), Right Angle | Brass | Female Sockets, Plug | Brass, Nickel | 250 VDC | Bronze | Metal | Nylon, Polyamide (PA) | Nickel | 85 °C | -40 °C | Screw | Silver | A | Backshell, Coupling Nut | Shielded | 3 µin | 0.076 µm | Industrial | 2 | Gold | 4 A | M12-2 | 4 mm, 6 mm | 0.157 in, 0.236 in | ||||
TE Connectivity AMP Connectors T4112001042-000 | IP67 - Dust Tight, Waterproof | Free Hanging (In-Line), Right Angle | Brass | Female Sockets, Plug | Glass Filled, Polybutylene Terephthalate (PBT) | 250 VDC | Bronze | Metal | Nylon, Polyamide (PA) | Nickel | 85 °C | -40 °C | Screw | Black, Silver | A | Backshell, Coupling Nut | Unshielded | 80 µin | 2.03 µm | Industrial | 4 | Silver | 4 A | M12-4 | 4 mm, 6 mm | 0.157 in, 0.236 in | ||||
TE Connectivity AMP Connectors T4112011051-000 | IP67 - Dust Tight, Waterproof | Free Hanging (In-Line), Right Angle | Brass | Female Sockets, Plug | Brass, Nickel | 60 VDC | Zinc Alloy | Metal | Nylon, Polyamide (PA) | Nickel | 85 °C | -40 °C | Screw | Silver | A | Backshell, Coupling Nut | Shielded | 3 µin | 0.076 µm | Industrial | Gold | 4 A | M12-5 | 4 mm, 6 mm | 0.157 in, 0.236 in | |||||
TE Connectivity AMP Connectors T4112002051-000 | IP67 - Dust Tight, Waterproof | Free Hanging (In-Line), Right Angle | Brass | Female Sockets, Plug | Glass Filled, Polybutylene Terephthalate (PBT) | 60 VDC | Zinc Alloy | Metal | Nylon, Polyamide (PA) | Nickel | 8 mm | 6 mm | 0.315 in | 0.236 in | 85 °C | -40 °C | Screw | Black, Silver | A | Backshell, Coupling Nut | Unshielded | 3 µin | 0.076 µm | Industrial | Gold | 4 A | M12-5 | |||
TE Connectivity AMP Connectors T4112011052-000 | IP67 - Dust Tight, Waterproof | Free Hanging (In-Line), Right Angle | Brass | Female Sockets, Plug | Brass, Nickel | 60 VDC | Bronze | Metal | Nylon, Polyamide (PA) | Nickel | 85 °C | -40 °C | Screw | Silver | A | Backshell, Coupling Nut | Shielded | 80 µin | 2.03 µm | Industrial | Silver | 4 A | M12-5 | 4 mm, 6 mm | 0.157 in, 0.236 in |
Description
General part information
T41120 Series
2 Position Circular Connector Plug, Female Sockets Screw
