MC30-2R2K-RC
ActiveAllied Components International
2.2UH10% 1812 MOLDED CHIP IND
MC30-2R2K-RC
ActiveAllied Components International
2.2UH10% 1812 MOLDED CHIP IND
Description
General part information
MC30-2R2K-RC
2.2 µH Unshielded Molded Inductor 700mOhm Max Nonstandard
Technical Specifications
Parameters and characteristics for this part
| Specification | MC30-2R2K-RC |
|---|---|
| Current - Saturation (Isat) | 380 mA |
| DC Resistance (DCR) (Max) | 700 mOhm |
| Frequency - Self Resonant | 55 MHz |
| Height - Seated (Max) | 0.138 in |
| Inductance | 2.2 µH |
| Inductance Frequency - Test | 7.96 MHz |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -25 °C |
| Package / Case | Nonstandard |
| Q | 50 |
| Shielding | Unshielded |
| Size / Dimension Length | 0.177 in |
| Size / Dimension Width | 0.126 in |
| Tolerance | 10 % |
| Type | Molded |
