Specification	DMP1080UCB4-7

Current - Continuous Drain (Id) (Ta)	3.3 A
Drain to Source Voltage (Vdss)	12 V
Drive Voltage (Max Rds On)	1.5 V
Drive Voltage (Min Rds On)	4.5 V
FET Type	P-Channel
Gate Charge (Max)	5 nC
Input Capacitance (Ciss) (Max)	350 pF
Mounting Type	Surface Mount
Operating Temperature (Max)	150 °C
Operating Temperature (Min)	-55 °C
Package / Case	4-UFBGA, WLBGA
Package Name	U-WLB1010-4
Power Dissipation (Max)	820 mW
Rds On (Max)	80 mOhm
Technology	MOSFET (Metal Oxide)
Vgs (Max)	-6 V
Vgs(th) (Max)	1 V
