Description
General part information
NHTI3001G332MJCG
Ceramic Capacitor
Technical Specifications
Parameters and characteristics for this part
| Specification | NHTI3001G332MJCG |
|---|---|
| Capacitance | 330 µF, 3300 µF |
| ESR (Equivalent Series Resistance) | 12 mOhm |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Ripple Current | 4250 mA |
| Size / Dimension Diameter | 0.63 in |
| Size / Dimension Length | 1.181 in |
| Tolerance | 20 % |
| Type | Polymer |
| Voltage - Rated | 40 V |
