704.006.718

Active

EAO

INDICATOR PANEL LED

Search across all available documentation for this part.

Active

EAO

INDICATOR PANEL LED

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

LED Panel Indicator Clear Screw Terminal

Technical documentation and resources

Specification	704.006.718	704.006 Series

	-	-
Features	-	Flashing LED
Ingress Protection	IP65	IP65
Lens Color	Colorless	Blue, Red, Yellow, Green, Colorless
Lens Size [diameter]	35 mm	29 - 35 mm
Lens Transparency	Clear	Clear
Panel Cutout Dimensions	1.2 in	0.88 - 1.2 in
Panel Cutout Dimensions	30.5 mm	22.3 - 30.5 mm
Panel Cutout Shape	Round	Round
Termination Style	Screw Terminal	Screw Terminal
Type	LED	LED

Part	Type	Lens Color	Lens Transparency	Lens Size [diameter]	Ingress Protection	Termination Style	Panel Cutout Shape	Panel Cutout Dimensions	Panel Cutout Dimensions	Features
EAO 704.006.618	LED	Blue	Clear	35 mm	IP65	Screw Terminal	Round	1.2 in	30.5 mm
EAO 704.006.318
EAO 704.006.2	LED	Red	Clear	29 mm	IP65	Screw Terminal	Round	0.88 in	22.3 mm
EAO 704.006.218	LED	Red	Clear	35 mm	IP65	Screw Terminal	Round	1.2 in	30.5 mm	Flashing LED
EAO 704.006.4	LED	Yellow	Clear	29 mm	IP65	Screw Terminal	Round	0.88 in	22.3 mm	Flashing LED
EAO 704.006.5	LED	Green	Clear	29 mm	IP65	Screw Terminal	Round	0.88 in	22.3 mm
EAO 704.006.718	LED	Colorless	Clear	35 mm	IP65	Screw Terminal	Round	1.2 in	30.5 mm
EAO 704.006.418	LED	Yellow	Clear	35 mm	IP65	Screw Terminal	Round	1.2 in	30.5 mm	Flashing LED
EAO 704.006.3
