CD10CD050DO3F
ActiveCornell Dubilier Knowles
CAP MICA 5PF 0.5PF 500V RADIAL
CD10CD050DO3F
ActiveCornell Dubilier Knowles
CAP MICA 5PF 0.5PF 500V RADIAL
Description
General part information
CD10CD050DO3F
5 pF Mica Capacitor 500 V Radial
Technical Specifications
Parameters and characteristics for this part
| Specification | CD10CD050DO3F |
|---|---|
| Capacitance | 5 pF |
| Dielectric Material | Mica |
| Features | General Purpose |
| Height - Seated (Max) | 0.331 in |
| Lead Spacing | 0.142 in |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Radial |
| Size / Dimension Length | 0.358 in |
| Size / Dimension Width | 0.189 in |
| Tolerance | 0.5 pF |
| Voltage - Rated | 500 V |
