280-678
ActiveWAGO Corporation
4-CONDUCTOR SHIELD TERMINAL BLOCK
280-678
ActiveWAGO Corporation
4-CONDUCTOR SHIELD TERMINAL BLOCK
Description
General part information
280-678
Terminal Block Connector 4 Position Ground, Earth White 12-28 AWG
Technical Specifications
Parameters and characteristics for this part
| Specification | 280-678 |
|---|---|
| Color | White |
| Material - Insulation | Polyamide, PA66, Nylon 6/6 |
| Material Flammability Rating | UL94 V-0 |
| Number of Levels | 1 |
| Number of Positions | 4 |
| Stripping Length (Max) | 9 mm |
| Stripping Length (Min) | 8 mm |
| Terminal Width | 5 mm |
| Termination Style | Push In, Spring |
| Type | Earth, Ground |
| Wire Gauge or Range - AWG (Max) | 28 AWG |
| Wire Gauge or Range - AWG (Min) | 12 AWG |
| Wire Gauge or Range - mm² (Maximum) | 2.5 mm² |
| Wire Gauge or Range - mm² (Minimum) | 0.08 mm² |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
