9R28014 000100
ActiveBelden Inc.
CBL RIBN 14COND 0.05 MULT
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
9R28014 000100
ActiveBelden Inc.
CBL RIBN 14COND 0.05 MULT
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 9R28014 000100 |
|---|---|
| Cable Type | Flat Cable |
| Conductor Material | Copper, Tinned |
| Conductor Strand [custom] | 7 |
| Conductor Strand [custom] | 36 AWG |
| Current Rating (Amps) | 1 A |
| Insulation Resistance | 10 GOhm |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC) |
| Jacket Color | Multiple |
| Length [x] | 100 ft |
| Length [x] | 30.48 m |
| Number of Conductors | 14 |
| Operating Temperature [Max] | 105 ░C |
| Operating Temperature [Min] | -20 C |
| Pitch [x] | 0.05 in |
| Pitch [x] | 1.27 mm |
| Ratings | UL Style 20932 |
| Ribbon Thickness | 0.91 mm |
| Ribbon Thickness | 0.036 " |
| Ribbon Width [x] | 0.7 in |
| Ribbon Width [x] | 17.78 mm |
| Shielding | Unshielded |
| Voltage | 300 V |
| Wire Gauge | 28 AWG |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Spool | 100 | $ 4.99 | |
Description
General part information
9R28014 Series
Flat Ribbon Cable Multiple 14 Conductors 0.050" (1.27mm) Flat Cable 100.0' (30.48m)
