B4-70CS
ActiveCentury Spring Corp
COMP O= .656,L= .38,W= .028
B4-70CS
ActiveCentury Spring Corp
COMP O= .656,L= .38,W= .028
Description
General part information
B4-70CS
COMP O= .656,L= .38,W= .028
Technical Specifications
Parameters and characteristics for this part
| Specification | B4-70CS |
|---|---|
| Diameter - Inside | 0.6 in |
| Diameter - Outside | 0.656 in |
| End Style | Closed |
| Finish | None |
| Free Length | 0.38 in |
| Material | Stainless Steel |
| Rate (lbs/in) | 3.1 lbs/in |
| Type | Compression |
| Wire Diameter | 0.028 in |
