CO21H4-45.1584-18KDTSTGK
ActiveSuzhou Hangjing Elec&Tech Co.,Ltd
XTAL OSC XO 45.1584MHZ HCMOS SMD
CO21H4-45.1584-18KDTSTGK
ActiveSuzhou Hangjing Elec&Tech Co.,Ltd
XTAL OSC XO 45.1584MHZ HCMOS SMD
Description
General part information
CO21H4-45.1584-18KDTSTGK
45.1584 MHz XO (Standard) HCMOS Oscillator 1.8V Enable/Disable 4-SMD, No Lead
Technical Specifications
Parameters and characteristics for this part
| Specification | CO21H4-45.1584-18KDTSTGK |
|---|---|
| Base Resonator | Crystal |
| Current - Supply (Max) | 10 mA, 15 mA |
| Frequency | 45.1584 MHz |
| Frequency Stability | 15 ppm, 25 ppm |
| Function | Enable, Disable |
| Height - Seated (Max) | 0.03 in, 0.033 in |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Output | HCMOS |
| Package / Case | 4-SMD, No Lead |
| Size / Dimension Length | 0.081 in |
| Size / Dimension Width | 0.065 in |
| Type | XO (Standard) |
| Voltage - Supply | 1.8 V |
