PI3PCIE2215ZHE

Obsolete

Diodes Inc

NRND = NOT RECOMMENDED FOR NEW DESIGN

Search across all available documentation for this part.

Obsolete

Diodes Inc

NRND = NOT RECOMMENDED FOR NEW DESIGN

Technical Specifications

Parameters and characteristics for this part

Specification	PI3PCIE2215ZHE

Applications	PCI Express®
Mounting Type	Surface Mount
Multiplexer/Demultiplexer Circuit	2:1
Number of Channels [custom]	2
On-State Resistance (Max) [Max]	12 Ohm
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Package / Case	28-VFQFN Exposed Pad
Supplier Device Package	28-TQFN
Supplier Device Package [x]	3.5
Supplier Device Package [y]	5.5
Voltage - Supply, Single (V+) [Max]	3.6 V
Voltage - Supply, Single (V+) [Min]	3 V

NRND = Not Recommended for New Design

Part	Number of Channels [custom]	Package / Case	On-State Resistance (Max) [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Multiplexer/Demultiplexer Circuit	Applications	Supplier Device Package [x]	Supplier Device Package [y]	Supplier Device Package	Mounting Type	Voltage - Supply, Single (V+) [Max]	Voltage - Supply, Single (V+) [Min]
Diodes Inc PI3PCIE2215ZHE	2	28-VFQFN Exposed Pad	12 Ohm	85 °C	-40 °C	2:1	PCI Express®	3.5	5.5	28-TQFN	Surface Mount	3.6 V	3 V
