770426-1

Active

TE Connectivity AMP Connectors

CONN PLUG HSG 9POS 3.68MM

Search across all available documentation for this part.

Active

TE Connectivity AMP Connectors

CONN PLUG HSG 9POS 3.68MM

Technical Specifications

Parameters and characteristics for this part

CONN PLUG HSG 9POS 3.68MM

Part	Pitch [x]	Pitch [x]	Note	Mounting Type	Number of Positions	Number of Rows	Contact Termination	Operating Temperature [Max]	Operating Temperature [Min]	Connector Type	Insulation Material	Contact Type	Fastening Type	Color	Row Spacing	Row Spacing
TE Connectivity AMP Connectors 770426-1	3.68 mm	0.145 in	Contacts Not Included	Panel Mount, Snap-In	9	3	Crimp	105 ░C	-55 °C	Plug	Nylon, Polyamide (PA)	Male or Female	Detent Lock	Natural	3.68 mm	0.145 in

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

9 Rectangular Connectors - Housings Plug Natural 0.145" (3.68mm)
