OKX2-T/10-D12N-C
ActiveMurata Power Solutions Inc.
NON ISOLATED POL DC/DC CONVERTER, 50 W, 750 MV, 5.5 V, 10 A, ADJUSTABLE, DOSA, SIP
Deep-Dive with AI
Search across all available documentation for this part.
OKX2-T/10-D12N-C
ActiveMurata Power Solutions Inc.
NON ISOLATED POL DC/DC CONVERTER, 50 W, 750 MV, 5.5 V, 10 A, ADJUSTABLE, DOSA, SIP
Deep-Dive with AI
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | OKX2-T/10-D12N-C | OKX2-T Series |
|---|---|---|
| Applications | - | ITE (Commercial) |
| Current - Output (Max) | - | 10 - 16 A |
| Efficiency | - | 94 - 95 % |
| Features | - | OTP, UVLO, SCP, Remote On/Off, OCP |
| Mounting Type | - | Through Hole |
| null | - | |
| Number of Outputs | - | 1 |
| Operating Temperature | - | 85 °C |
| Operating Temperature | - | -40 °C |
| Package / Case | - | 11-SIP Module |
| Power (Watts) | - | 50 - 80 W |
| Size / Dimension | - | 50.8 mm |
| Size / Dimension | - | 0.37 " |
| Size / Dimension | - | 2 in |
| Size / Dimension | - | 0.5 in |
| Size / Dimension | - | 12.7 mm |
| Size / Dimension | - | 9.4 mm |
| Type | - | Non-Isolated PoL Module |
| Voltage - Input (Max) | - | 5.5 - 14 V |
| Voltage - Input (Min) | - | 2.4 - 8.3 V |
| Voltage - Output 1 | - | 3.63 - 5.5 V |
| Voltage - Output 1 | - | 0.75 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
OKX2-T Series
NON ISOLATED POL DC/DC CONVERTER, OKAMI, 80 W, 750 MV, 5.5 V, 16 A, ADJUSTABLE, DOSA, SIP
| Part | Applications | Current - Output (Max) [Max] | Voltage - Input (Max) [Max] | Type | Voltage - Input (Min) [Min] | Operating Temperature [Max] | Operating Temperature [Min] | Package / Case | Number of Outputs | Features | Voltage - Output 1 [Max] | Voltage - Output 1 [Min] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [y] | Power (Watts) | Mounting Type | Efficiency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Murata Power Solutions Inc. OKX2-T/16-D12N-C | ITE (Commercial) | 16 A | 14 V | Non-Isolated PoL Module | 8.3 V | 85 °C | -40 °C | 11-SIP Module | 1 | OCP, OTP, Remote On/Off, SCP, UVLO | 5.5 V | 0.75 V | 50.8 mm | 0.37 " | 2 in | 0.5 in | 12.7 mm | 9.4 mm | 80 W | Through Hole | 94 % |
Murata Power Solutions Inc. OKX2-T/10-D12N-C | |||||||||||||||||||||
Murata Power Solutions Inc. OKX2-T/16-W5N-C | ITE (Commercial) | 16 A | 5.5 V | Non-Isolated PoL Module | 2.4 V | 85 °C | -40 °C | 11-SIP Module | 1 | OCP, OTP, Remote On/Off, SCP, UVLO | 3.63 V | 0.75 V | 50.8 mm | 0.37 " | 2 in | 0.5 in | 12.7 mm | 9.4 mm | 53 W | Through Hole | 95 % |
Murata Power Solutions Inc. OKX2-T/10-D12N-C | ITE (Commercial) | 10 A | 14 V | Non-Isolated PoL Module | 8.3 V | 85 °C | -40 °C | 11-SIP Module | 1 | OCP, OTP, Remote On/Off, SCP, UVLO | 5.5 V | 0.75 V | 50.8 mm | 0.37 " | 2 in | 0.5 in | 12.7 mm | 9.4 mm | 50 W | Through Hole | 94.5 % |
Murata Power Solutions Inc. OKX2-T/16-D12N-C |
Description
General part information
OKX2-T Series
Non-Isolated PoL Module DC DC Converter 1 Output 0.75 ~ 5.5V 10A 8.3V - 14V Input
