0175M4-6.000F20DTNJK
ActiveSuzhou Hangjing Elec&Tech Co.,Ltd
CRYSTAL 6MHZ 20PF SMD
0175M4-6.000F20DTNJK
ActiveSuzhou Hangjing Elec&Tech Co.,Ltd
CRYSTAL 6MHZ 20PF SMD
Description
General part information
0175M4-6.000F20DTNJK
6 MHz ±10ppm Crystal 20pF 100 kOhms 4-SMD, No Lead
Technical Specifications
Parameters and characteristics for this part
| Specification | 0175M4-6.000F20DTNJK |
|---|---|
| ESR (Equivalent Series Resistance) | 100 Ohm, 100 kOhm |
| Frequency | 6 MHz |
| Frequency Stability | 30 ppm |
| Frequency Tolerance | 10 ppm |
| Height - Seated (Max) | 0.039 in, 0.047 in |
| Load Capacitance | 20 pF |
| Mounting Type | Surface Mount |
| Operating Mode | Fundamental |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | 4-SMD, No Lead |
| Package Length | 7 mm |
| Package Name | 4-SMD |
| Package Width | 5 mm |
| Size / Dimension Length | 0.276 in |
| Size / Dimension Width | 0.197 in |
| Type | MHz Crystal |
