MS27467E11Z98PD

Active

Corsair

PLUG STRAIGHT CABLE

Search across all available documentation for this part.

Active

Corsair

PLUG STRAIGHT CABLE

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	MS27467E11Z98PD	MS27467E11Z Series

Applications	Military, Aerospace	Military, Aerospace
Connector Type	Plug, Male Pins	Female Sockets, Plug, Male Pins
Contact Finish - Mating	Gold	Gold
Fastening Type	Bayonet Lock	Bayonet Lock
Features	Coupling Nut	Coupling Nut
Grade	Military	Military
Ingress Protection	IP67	IP67
Insert Material	Thermoplastic	Thermoplastic
Material Flammability Rating	UL94 V-0	UL94 V-0
Mounting Type	Free Hanging (In-Line)	Free Hanging (In-Line)
Operating Temperature [Max]	200 °C	200 °C
Operating Temperature [Min]	-65 ░C	-65 ░C
Orientation	D	A, D
Primary Material	Metal	Metal
Qualification	MIL-DTL-38999 Series I	MIL-DTL-38999 Series I
Shell Size, MIL	A	A
Shielding	Shielded	Shielded
Termination	Crimp	Crimp

PLUG STRAIGHT CABLE

Part	Features	Grade	Connector Type	Mounting Type	Fastening Type	Insert Material	Orientation	Ingress Protection	Material Flammability Rating	Applications	Shielding	Shell Size, MIL	Qualification	Operating Temperature [Min]	Operating Temperature [Max]	Contact Finish - Mating	Primary Material	Termination
Corsair MS27467E11Z4SA	Coupling Nut	Military	Female Sockets, Plug	Free Hanging (In-Line)	Bayonet Lock	Thermoplastic	A	IP67	UL94 V-0	Aerospace, Military	Shielded	A	MIL-DTL-38999 Series I	-65 ░C	200 °C	Gold	Metal	Crimp
Corsair MS27467E11Z98PA	Coupling Nut	Military	Male Pins, Plug	Free Hanging (In-Line)	Bayonet Lock	Thermoplastic	A	IP67	UL94 V-0	Aerospace, Military	Shielded	A	MIL-DTL-38999 Series I	-65 ░C	200 °C	Gold	Metal	Crimp
Corsair MS27467E11Z98SA	Coupling Nut	Military	Female Sockets, Plug	Free Hanging (In-Line)	Bayonet Lock	Thermoplastic	A	IP67	UL94 V-0	Aerospace, Military	Shielded	A	MIL-DTL-38999 Series I	-65 ░C	200 °C	Gold	Metal	Crimp
Corsair MS27467E11Z98PD	Coupling Nut	Military	Male Pins, Plug	Free Hanging (In-Line)	Bayonet Lock	Thermoplastic	D	IP67	UL94 V-0	Aerospace, Military	Shielded	A	MIL-DTL-38999 Series I	-65 ░C	200 °C	Gold	Metal	Crimp

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Position Circular Connector Plug, Male Pins Crimp
