Description
General part information
CPRX3231L-250MC
25 µH Shielded Wirewound Inductor 32 A 2.5mOhm Max Radial, Horizontal (Open) Flat Wire, High Current
Technical Specifications
Parameters and characteristics for this part
| Specification | CPRX3231L-250MC |
|---|---|
| Current - Saturation (Isat) | 50 A |
| Current Rating | 32 A |
| DC Resistance (DCR) (Max) | 2.5 mOhm |
| Features | Flat Wire, High Current |
| Height - Seated (Max) | 1.181 in |
| Inductance | 25 µH |
| Inductance Frequency - Test | 100 kHz |
| Material - Core | Metal Composite |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 155 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Horizontal (Open), Radial |
| Package Name | Radial, Horizontal (Open) |
| Shielding | Shielded |
| Size / Dimension Length | 1.291 in |
| Size / Dimension Width | 1.26 in |
| Tolerance | 20 % |
| Type | Wirewound |
