Description
General part information
FCR2WSJR-52-6K2
6.2 kOhms ±5% 2W Through Hole Resistor Axial Flame Proof, Safety Carbon Film
Technical Specifications
Parameters and characteristics for this part
| Specification | FCR2WSJR-52-6K2 |
|---|---|
| Composition | Carbon Film |
| Features | Safety, Flame Proof |
| Number of Terminations | 2 |
| Operating Temperature (Max) | 155 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Axial |
| Package Name | Axial |
| Power (Watts) | 2 w |
| Resistance | 6.2 kOhm |
| Size / Dimension Diameter | 0.177 in |
| Size / Dimension Length | 0.453 in |
| Temperature Coefficient (Highest) | 350 ppm/°C |
| Temperature Coefficient (Lowest) | -350 ppm/°C |
| Temperature Coefficient (Negative) | -350 ppm/°C |
| Temperature Coefficient (Positive) | 350 ppm/°C |
| Tolerance | 5 % |
