Description
General part information
TTR31-A1C121AA2CAB
Thermostat PNP
Technical Specifications
Parameters and characteristics for this part
| Specification | TTR31-A1C121AA2CAB |
|---|---|
| Current - Output (Max) | 250 mA |
| Current - Supply | 60 mA |
| Features | Selectable Hysteresis |
| Mounting Type | Panel Mount |
| Operating Temperature (Max) | 150 °C |
| Operating Temperature (Min) | -50 °C |
| Output Type | PNP |
| Package / Case | Threaded, Cylinder |
| Selectable Hysteresis | Yes |
| Trip Temperature Threshold | Hot |
| Voltage - Supply (Maximum) | 30 VDC |
| Voltage - Supply (Minimum) | 12 VDC |
