A41-130-16L
ActiveSignal Transformer
PWR XFMR LAMINATED 130VA CHAS MT
A41-130-16L
ActiveSignal Transformer
PWR XFMR LAMINATED 130VA CHAS MT
Description
General part information
A41-130-16L
PWR XFMR LAMINATED 130VA CHAS MT
Technical Specifications
Parameters and characteristics for this part
| Specification | A41-130-16L |
|---|---|
| Center Tap | No |
| Current - Output (Max) Parallel | 16.2 A |
| Current - Output (Max) Series | 8.1 A |
| Height - Seated (Max) | 85.7 mm |
| Mounting Type | Chassis Mount |
| Power - Max | 130 W |
| Primary Winding(s) | Dual |
| Secondary Winding(s) | Dual |
| Size / Dimension Length | 71.4 mm |
| Size / Dimension Width | 76.2 mm |
| Termination Style | Wire Leads |
| Type | Laminated Core |
| Voltage - Isolation | 4000 Vpk |
| Voltage - Primary | 230V, 115V |
| Voltage - Secondary (Full Load) (Parallel) | 8 V |
| Voltage - Secondary (Full Load) (Series) | 16 V |
| Weight | 4.1 lbs |
